|Name:||Roll Forming Equipment||Thickness:||0.4-0.8mm|
|Application:||Wall Panel||Roller Material:||45# Steel Coated With Hard Chrome|
|Main Motor Power / Hydraulic Station Power:||5.5kW / 3kW||Forming Speed:||5-15 Meters/minute|
corrugated sheet roll forming machine,
metal roof roll forming machine
GWC38-300 Wall Panel Thickness 0.4-0.8mm Roll Forming Machine
Wall Panel Roll Forming Machine
The wall panel roll forming machine is designed to make favored wall panels that are used to build walls of many industrial and civilian constructions around the world, including workshop, warehouse, hangar, gymnasium, theatre, exhibition hall, engine house, etc.
1. The finished panel has small depth and large pitch. Thus, it is relatively easier to manufacture this machine, and the price is moderate.
2. The wall panel itself has reinforcing rib, and corrugation is not generated during production. Its mechanical strength makes it suitable for general use.
3. There is no need to redesign the wall panel roll forming machine, so the production cycle is reduced greatly. In addition, customized products are also available if relevant drawings and requirements are provided.
Passive decoiling → guided material feeding → roll forming → cut-to-length → offloading
1. 5T passive decoiler
2. Shape forming machine
3. Hydraulic shear
4. Hydraulic station
5. PLC control cabinet
6. Run out table
|Applicable material||Color plate, galvanized sheet, galvalume sheet, aluminum plate||This machine is customizable upon each customer's requirements and the characteristics of processed material.|
|Roller material||45# steel coated with hard chrome|
|Main motor power / hydraulic station power||5.5kW / 3kW||These parameters can be set according to the required production capacity.|
|Forming passes||18 passes||18 passes||24 passes|
|Forming speed||5-15 meters/minute|
