| After-Sales Service Provided: | Online Support, Field Installation, Commissioning | Production Capacity: | 10-15m/Min |
|---|---|---|---|
| Certification: | CE/ISO9001 | Condition: | New |
| Use: | Roof | Voltage: | 380V 50Hz 3phases |
| High Light: | metal roofing sheet making machine,roof panel roll forming machine |
||
Cover Panel of Ship Roll Forming Machine
4. Hydraulic station
5. PLC control cabinet
6. Run out table
Specifications
| Model | Note | |
| Applicable material | Color plate, galvanized sheet, galvalume sheet, aluminum plate | This machine is customizable upon each customer's requirements and the characteristics of processed material. |
| Feeding width | 600mm | |
| Processing thickness | 0.3-0.8mm | |
| Roller material | 45# steel coated with hard chrome | |
| Main motor power / hydraulic station power | 5.5kW / 4kW | These parameters can be set according to the required production capacity. |
| Forming passes | 17 | |
| Forming speed | 5-15 meters/minute | |
| Machine dimensions | 9.5×1.3×1.2m | |
| Machine weight | 7T |
Related Names:
Corrugated steel panel for shipbuilding roll forming machine / tapered shape steel panel of ship roll forming machine / steel wallboard of vessel manufacturing machine /heavy gauge sheet of boat roll forming machine /Steel skin of ship roll forming machine /Metal covering of vessel forming equipment / Heavy gauge skin of ship forming line
