Product Details:
Payment & Shipping Terms:
|
Name: | Steel Silo Forming Machine | Thickness: | 0.8-4.0mm |
---|---|---|---|
Control System: | Plc Control | Speed: | 15m/Min |
Motor Power: | About 152kw | Use: | Storage Of Food |
High Light: | automatic roll forming machine,cold roll forming line |
1.5-4.0 mm grain bin Corrugated Galvanized Sheet Silo Roll Forming Machine
The assembled silo that is composed of galvanized corrugated sheet is widely used for the purpose of commercial grain storage around the world, and our assembled silo corrugated sheet roll forming machine is especially designed to manufacture such steel sheets.
Features:
1) Material of the profile: 195-235Mpa GI or carbon steel
2) Thickness range: 3-4mm
3) Main motor power:60kw, AC motor, motor inside of main machine (Brand: Guomao of China) (according the final design)
4) Machine Voltage, Frequency, Phase: 380 V, 50 Hz, 3Phase
5) Roll station: about 20 stations (according the final design)
6) Roller material:Gcr15 bearing material chrome plated surface with hardness 58-62 degree ,CNC,
7) Shaft diameter: 150mm material: SAE1045 with quenching and tempering
8) Machine roll forming speed:18m/min
9) Transmission: by gear box 200*500(outside is cast iron, surface needed polish and paint. Inside is 60# forge and press metal)
10) Roll former has leveling bolts in the base for adjust the leveling
11) Machine base frame adopt H beam welding steel
12) In the main roll forming machine have 2 buttons for urgency stop if happen any malfunction.
13) Machine adopt new station to make machine more strong
14) To avoid accidents,all of drive part adopt protect cover
15) Color of machine: Blue and yellow (or base on customer request)
Specification of Ceiling Silo Roll Forming Machine
NO. | Items | Unit | Parameters | |
1 |
Material |
Type | Low carbon steel,Galvanized steel,etc | |
Tensile strength | Map | ≥450 | ||
Thickness | mm | 0.8-4.0mm | ||
2 | Production speed | m/min | 4 | |
3 | Roller material | GCr15 Quenching treatment | ||
4 | Drive type | Gearbox | ||
5 | Motor power | kw | About 152 | |
6 | Electric control system | PLC frequenvy motor | ||
7 | Dimension(Length*Width*Height) | m | 40X5X3.9 |
Machine list:
Number | Machine list | Number |
1 | 5 tons hydraulic decoiler | 1 set |
2 | Feeding&leveling device | 1 set |
3 | Gear box drive system | 1 set |
4 | Main forming machine | 1 set |
5 | Curving device | 1 set |
6 | Hydraulic Cutting device | 1 set |
7 | Auto stacker 6 meters | 1 set |
8 | PLC control system | 1 set |
9 | Hydraulic station | 1 set |
Application:
Steel silo corrugated sheet, steel silo corrugated panel, silo wall sheet, silo corrugated wall sheet, silo wall panel, silo corrugated wall panel, silo side panel, steel corrugated sheet, steel corrugated wall panel, steel corrugated panel.
Machine Specifications
Packaging & Shipping
1 . Before loading to the container, we will check the machine first
2 . make some protection on the machine, such as, we will paint the coil on the roller and shaft, in case the roller and shaft got corrosion and rusty during long time delivery
3 . we will make the plastic package on the easy damage parts, and fix all the parts into container by the steel wire rope, and ensure the machine will not
4 . we will take photos for customer when loading to container.
