Product Details:
Payment & Shipping Terms:
|
| Weight: | 8.0 - 13.0 Tons | Warranty: | 1 Year,one Year |
|---|---|---|---|
| Voltage: | 380V 50Hz 3Phases Or As Your Requirment | Color: | Customized |
| Name: | Corrugated Cold Roll Forming Machine,steel C Channel Roll Forming Machine | Raw Material: | Galvanized Sheet,PPGI/Galvanized Sheet |
| High Light: | wall panel forming machine,automatic roll forming machine |
||
Cold Roll Forming Machine for Spiral Steel Silo
Silo Features
Through the 5 forming procedures and 5 kind of steel strip forming merge suturing machine steel strip(thickness:2-4mm;495mm)will be merged forcedly and suture spirally to make cylinder with 4-50m of different diameters.
These steel cylinders are used widely:
1. Material shape (storage): granular material, powder material, liquid material
2. Industry: grain, feed brewing, oil, medicine, food, cement, water treatment
3.Concrete variety(storage): wheat, soybean, maize, sorghum wheat flour, bulk cement fly-ash, sewage, water, chemical syrup
Technical Parameters of Cold Roll Forming Line
| Applicable Material | Galvanized sheet |
| Material Width | ≤500mm |
| Processing Thickness | 4.0mm |
| Roller Material | Cr12Mov alloy steel processed with heat treatment, HRC55 |
| Main Motor Power/Hydraulic Station Power | 15kW/15kW |
| Forming Step | 5 times forming and 6 times seaming |
| Machine Size | 8m×2m×2m |
| Machine Weight | 20 tons |
Related Names
Spiral Grain Bin Forming Machine | Spiral Grain Storage System Machine | Helix Grain Bin Production Line | Helix Silo Machine | Helical grain silo machine
