Product Details:
Payment & Shipping Terms:
|
| Name: | Cold Roll Forming Machine | Condition: | New |
|---|---|---|---|
| Dimension(l*w*h): | 5000*800*1200Mm,8100*1700*1500mm Etc | Use: | Garage,downpipe,Anti-vibration |
| Usage: | Roofing Accessories,Automatic Roof Sheet Cold Roll Forming Machinery,floor | Tile Type: | Steel Forming Machine |
| High Light: | cz purlin roll forming machine,guardrail roll forming machine |
||
0.8-4.0 mm grain bin Corrugated Galvanized Sheet Silo Roll Forming Machine
Specification of Ceiling Silo Roll Forming Machine
| NO. | Items | Unit | Parameters | |
|
1 |
Material |
Type | Low carbon steel,Galvanized steel,etc | |
| Tensile strength | Map | ≥450 | ||
| Thickness | mm | 0.8-4.0mm | ||
| 2 | Production speed | m/min | 4 | |
| 3 | Roller material | GCr15 Quenching treatment | ||
| 4 | Drive type | Gearbox | ||
| 5 | Motor power | kw | About 152 | |
| 6 | Electric control system | PLC frequenvy motor | ||
| 7 | Dimension(Length*Width*Height) | m | 40X5X3.9 | |
Machine list:
| Number | Machine list | Number |
| 1 | 5 tons hydraulic decoiler | 1 set |
| 2 | Feeding&leveling device | 1 set |
| 3 | Gear box drive system | 1 set |
| 4 | Main forming machine | 1 set |
| 5 | Curving device | 1 set |
| 6 | Hydraulic Cutting device | 1 set |
| 7 | Auto stacker 6 meters | 1 set |
| 8 | PLC control system | 1 set |
| 9 | Hydraulic station | 1 set |
Packaging & Shipping
1 . Before loading to the container, we will check the machine first
2 .make some protection on the machine, such as, we will paint the coil on the roller and shaft, in case the roller and shaft got corrosion and rusty during long time delivery
3 .we will make the plastic package on the easy damage parts, and fix all the parts into container by the steel wire rope, and ensure the machine will not
4 .we will take photos for customer when loading to container.
Main product :
Roof roll forming machine
C and Z purlin roll forming machine
Downpipe roll forming machine
Hydraulic decoiler
Light keel roll forming machine6
Bending machine
Shearing machine
slitting machine
Roller shutter door roll forming machine
Features:
1 . The equipment control is PLC control, and multiple safety protection is set during normal production.
2 . The bed is welded with steel plates. It is also tempered to eliminate internal stress and avoid deformation of the fuselage.
3 . The forming frame is cast iron structure and tempered. High strength and long service life.
4 . The material of the roll shaft is 40Cr, and the hardness is HB280 after quenching and tempering treatment.
5 . The material of the forming mold is GCr15, quenching treatment, hardness: HRC 56-62 °C.
6 . The transmission structure is gearbox transmission. Each molding frame has a gearbox that guarantees time-out, high-intensity operation, and long service life.
